Navisworks for Clash Detection

The Clash Detective tool available in the Autodesk Navisworks Manage product enables the effective identification, inspection, comment tracking, and reporting of interference in a 3D project model. Clash Detective can eliminate a tedious manual task, with the accompanying risk of human error, to significantly reduce the expensive consequences of incomplete, inaccurate, and poorly coordinated production information. Simplify project coordination. Clash Detective will link the responsible parties to track the clash through the project lifecycle. If you need to complete design projects on time and in budget, this 1-day Navisworks for Clash Detection course is your chance to gain those skills.

Course content for Navisworks for Clash Detection:

  • Learn how to integrate all project models into a single aggregate model
  • Work with object properties, measure tools, viewpoints,  mark-ups and animations
  • Import live data from external databases and display within the model
  • Store, organize, and share camera views of a design and export them into images or reports
  • Add cross sections and section plans to inspect details
  • Publish and store project models in a single distributable NWD or DWF™ file
  • Compress original project file size by up to 90%
  • Embed or exclude object properties
  • Add mark-ups with advanced redlining tools
  • Include date-stamped audit trail for your project notes
  • Record animated walkthroughs for real-time playback
  • Use advanced navigation tools such as gravity and solid object recognition
  • Set clash rules, understand clash results, clash test reporting, work with clash tests
  • Export and import clash tests, custom clash tests
  • Laser scan data clashing
  • Hold and release objects
  • Switchback in clash detective to report to authoring software
  • Phasing – save costs with time-based clashing
  • Add materials to your model, create / edit materials, lighting, sun and sky lights
  • Exposure control, ground planes, photorealistic rendering

Benefits of Navisworks Training

Eliminate a tedious manual task
Reduce the risk of human error
Simplify project coordination
Complete design projects on time and on budget

Expected outcome

As a result of attending this course, you will open and append 3D files of different formats and save them in a Navisworks format, work with object properties, measuring tools, search tools, redlining, snapshot a scene, create sectional cuts, link objects, compare models, perform visual project model reviews using the built-in review and reporting tools, use real time rendering and lighting modes, identify, inspect, track and report on interference in a 3D project model, complete the course by applying your new clash detection skills to your own 3D model using your data, in an open application lab.

Expected outcome
