Remove Unnecessary Coplanar Edges with CleanUp - a SketchUp Extension

 As mentioned in my previous blog post, there are hundreds of extensions - tools and features - integrated directly into SketchUp Pro which improve conceptual design modelling workflows and reduce time-consuming, complex or repetitive processes.

I thought I would list my recommendation of the very basic SketchUp extensions which I’m sure your Conceptual Design Modelling Teams and Users will find useful. In the first blog post, I presented Weld - an extension which joins connected edges and broken lines into one continuous polyline.

Here is my second extension recommendation:

CleanUp

A superb plugin to remove unnecessary coplanar edges and clean up imported geometry. This SketchUp extension can also be used to:

  • Fix duplicate component definition names (when in model scope)
  • Purge unused items
  • Erase hidden geometry
  • Erase duplicate faces
  • Erase lonely edges (except edges on cut plane)
  • Remove edge material
  • Repair split edges
  • Smooth and soften edges
  • Put edges and faces to Layer0
  • Merge identical materials
  • Merge connected co-planar faces

The CleanUp SketchUp extension is perfect for the following industries:
Architecture, Construction, Education, Engineering, Film & Stage, Gaming, Heavy Civil, Interior Design, Kitchen & Bath, Landscape Architecture, Urban Planning, Woodworking

Watch a demonstration of CleanUp below.


Look out for SketchUp Extension recommendation number 3 which will be posted shortly. In the meantime, you can explore other SketchUp plugins here.

Learn more about SketchUp Pro here
